DESCRIPTION
- Temporarily out of stock, will be available by Feb 5th 2023.
- CEILING MOUNT WITH REMOTE CONTROLL: The blower unit is mounted in the attic and the hood unit is mounted in the ceiling. The ceiling mount improves ventilation and lighting over your kitchen while there is a limitation to install a range hood right above the stove. Wireless remote control to turn on and adjust the speeds. Built with high quality 1mm thick stainless steel with a brush finishing.
- DUCTED VENT OUTSIDE, 8” ROUND TOP VENT: 8” round top exhaust vent (NO rear vent). CAUTION: please check your existing venting duct before purchasing, there are rectangle or round ducts at different sizes. Ducts are not included.
- 4 SPEEDS POWERFUL OPERATION WITH LED LIGHTS: 4 speeds (Q, I, II, III up to 1000 CFM), touch sensor panel with a remote control. 2 3W energy saving cold bright LED lights. 1 motor in the blower unit. The blower unit needs to be installed in the attic to reduce the noise in the kitchen. Power rating: 120V/60Hz, 110W Min /160W Max. 12 ft split control cord and power cord with plug is included. Noise level at low: 40 dB, 2.5 sones. Noise level at high: 52 dB, 5.5 sones.
- DISHWASHER SAFE BAFFLE FILTERS: Dishwasher safe commercial style stainless steel baffle air filters. The oil is contained in the baffle filters, no oil holders needed.
- 1 YEAR USA LIMITED PARTS WARRANTY: ETL Certified. Free parts, repair or exchange within 1 year. Awoco high quality product reputation and supreme customer service is a guarantee.
- 30" Hood unit overall dimensions: 27-5/8"W x 14-1/2"D x 4-1/8"H. Hood weight: 15 lbs.
- 36" Hood unit overall dimensions: 35-3/8"W x 14-1/2"D x 4-1/8"H.
- Blower unit overall dimensions: 14-5/8"W x 14-3/4"D x 14-3/4"H. Blower weight: 27.5 lbs.
SHIPPING & RETURN
FULFILLMENT / DELIVERY
- Dispatch: Within 48 Hours
- Free shipping across all products
- Domestic delivery time - 4-10 business days (Mainland USA ONLY)
- Easy 30 days returns and exchanges
- Please look at our "Shipping Policy" section for further information.
RETURNS
SPECIFICATIONS
Mounting Type | • Hood Unit: Under Cabinet or Wall-Mount. • Blower Unit: Attic Lumber-Mount. |
Venting | • Hood Unit: 8" round TOP vent. • Blower Unit: 8" round vent in and out. |
Power Rating | 120V~60Hz. |
Lighting | 2x 1.5W LED. |
Noise Level | 40dB / 50dB / 54dB / 58dB. |
Model No. | A | B | C | # of Baffle Filters | Max CFM | Min Wattage | Max Wattage |
RH-IT08-M30 | 27-3/4" | 25-7/8" | 8" | 2 | 1000 | 135W | 250W |
RH-IT08-M36 | 35-3/8" | 33-7/8" | 3 |
USER-MANUAL DOWNLOAD
AWOCO USER MANUAL PDF: VIEW / DOWNLOAD
AWOCO SERVICE VIDEOS
SERVICE HELP: AWOCO 101 VIDEOS
Awoco RH-IT08-R Ceiling Mount 14-1/2”D Super Quiet Split Stainless Steel Range Hood, 4-Speed, 1000 CFM, Remote Control with 8” Blower
